Weld-On Roller Bearing Hinge1400 lb per pair

• Made in the USA.
• Pivot type weld-on hinge with sealed roller bearings.
• 220 Degree swing range.
• Features a nylon locking nut on the bottom of the pivot bolt.
• Sold by the pair. A pair (two hinges) is what is normally needed to hang one gate.

1400 lb Model Dimensions:

• Post side welding plate is 1.5″ x 3.5″.
• Gate side welding plate is 1.5″ x 2.75″.
• Spacing between the gate and post is 2.71″.
• Pivot bolt is 0.5″ x 4″.

1700 lb Model Dimensions:

• Post side welding plate is 2″ x 4.25″.
• Gate side welding plate is 2″ x 3.25″.
• Spacing between the gate and post is 4.25″.
• Pivot bolt is 0.672″ x 5″.
