IVES 69F10B 69 Hinge Pin Door Stop, Oil Rubbed Dark Bronze

• Part of the Schlage Family of Products
• Steel Material
• Mounting Hardware Included
• Features Solid Construction for Increased Strength
• Limited 1 Year Warranty

Finish

Oil Rubbed Dark Bronze

Series

Parts/Accessories

Color

Dark Oxidized Satin Bronze Oil Rubbed

Color Code

613/US10B

Package Qty

1

Base Material

Steel

Finish Description

Oil Rubbed Dark Bronze

Product Type

Door Accessory

Tip Size

9/16″ Dia

For Use With

3-1/4″ or 4″ Hinged Doors

Application

Commercial and Residential Applications

Function

Door Stop

Base Size

1″ Dia

Tip Material

Non-Marring Rubber

ADA Compliant

No

Finish Family

Dark Bronze

Product Material

Burnished Wrought Steel

Standards

ANSI/BHMA 156.16

Function Family

Door Accessory

Product Projection

3-1/4 Inch

Features

Positive Slip Proof Adjustment; Adjustable for 70 to 100 Door Openings; Removable Bushings Accommodate 1/4 in to 5/16 in Diameter Hinge Pins; Easy Installation only a Screwdriver Required; Economical Solution for Use on Low Frequency, Light Weight

Manufacturer Parent

Allegion

Tip Color

White

Sub-Series

DTA_Door_Stops_Holders_ives_9

Product Overview 69 Hinge pin door stops

• Economical solution for use on low frequency, light weight, residential 3 1/2 or 4″ hinged doors where the installation of a standard door stop or overhead is not desirable
• Adjustable for 70 to 100 degree Door Openings
• Positive slip proof adjustment
• White non-marring rubber tips
• Removable bushings accommodate 1/4 to 5/16 diameter hinge pins
• Easy installation – only a screwdriver required

Material substrate

• Made from burnished wrought steel
