Blum Mini Hinge for Back-to-Back Overlay Cabinets – Bundle

• Blum’s mini half cranked clip top hinge for back-to-back doors.
• For doors with a narrow style or for smaller sized doors.
• Fits in a 26mm cup drilled in the back of the door.
• Please see the “Reveal & Overlay Information” document below to verify if this bundle will work for your application.

What’s Included

• 1 Blum Mini Half Cranked Hinge
• 1 Blum System Screw 0mm Frameless Mounting Plate
• Two #6 x 5/8″ Flat Head Wood Screws for the hinge

Mounting Screws for Mounting Plate (Not Included)

• Depending on cabinet side wall thickness you will need either of the following screws for the mounting plate:
  • For cabinet wall thickness of 5/8″ to 7/8″, you will need to use back to back mounting screws.
  • For cabinet wall thickness of 1″ or greater, use #6 x 5/8″ screws.
• Note that only two back to back screws are required for two hinges, whereas you would need four #6 x 5/8″ screws for two hinges.

Optional Accessories -Available for purchase separately:

• Cover Plate for Arm Part of Hinge – Hides the screws on the hinge arm providing a cleaner appearance
• Plastic Dowels, used on manufactured wood products where wood screws do not hold well (SKU 652368)
• Blum Touch Latch for Self-Closing Doors (SKU 268822)
• Blum Stand Alone Soft-Close Device (SKU G10006)
